The product uses internal digital temperature control, with touch-tone and touch-screen controllers.
Check compatibility before buying products with power plugs, as sockets and voltage differ by country. You may need an adapter or converter for your destination.
Model | SAF-60 | SAF-90 | SAF-120 | SAF-150 | SAF-180 |
Power(kW) | 6 | 9 | 12 | 15 | 18 |
Heating Element(kW) | 3×2.0 | 3×3.0 | 6×2.0 | 3*2.0 3*3.0 | 6*3.0 |
Sauna Room(m³) | 5 to 8 | 8 to 15 | 11 to 18 | 18 to 28 | 18 to 30 |
Voltage | 230V1N~/400V2N~ | 400V 3N | |||
Size Of Heater(Width*Height)(mm) | 350*840 | 380*840 | |||
Size OF Wire(mm²) | 5×2.5 | 5×4.0 | |||
Stones(kg) | 85 | 100 |
Model Number: | SAF-60 |
Function: | Dry Steam |
Feature: | DO-AT86 touch screen controller |
Main Material: | Stainless Steel |
Heating Elements material | Stainless Steel 840 with UL Certificate |
Power: | 6KW |
Voltage: | 220-240V/380-415V |
Frequency: | 50 hz-60hz |
Capacity: | 5-8CBM |
Usage: | sauna center, beauty salon |
Warranty: | 3 years |
Product dimension: | Φ350×760MM |
package size | 400×400×850MM |
weight: | 14KG |
Business mode: | Factory directly |
Features | Auto power off | Power off automatically |
Time setting | 30min-12Hour | |
Temperature setting | 50~110℃ | |
Touch screen control panel | The controller is installed outside the sauna room |
Optional controller |
DO-AT86 touch screen controller | 30m-12H/50~110℃ |
DO-135M touch screen controller | 1-12H/50~110℃ | |
DO-135T1 touch screen controller | 1-12H/50~110℃ | |
DO-135T2 touch screen controller | 1-12H/50~110℃ | |
DO-135T3 touch screen controller | 1-12H/50~110℃ |
ID | Model Number | Image |
1 | DO-135T3 | |
2 | DO-135T2 | |
3 | DO-135T1 | |
4 | AT-100 |
ID | Model Number | Image |
5 | CON4 LED Controler | |
6 | DO-AT86 | |
7 | DO-135M |
